Description
Brand: CHINS
Features:
- 【Bluetooth function】: Compared with the traditional battery monitor, CHINS lithium battery has added Bluetooth function and can obtain various data (SOC) of the lithium iron phosphate battery. Customers can connect to the battery through the mobile phone APP, and read the battery voltage, current and other important information at any time. Wireless connection range: within 5-10 meters from the battery.
- 【Capacity Expansion】: CHINS LiFePO4 battery can be connected in parallels and in series for larger capacity and voltage. Max connection in series: Up to 2 identical batteries for up to 48V connecting in series. Connection in parallels: it can connect multiple batteries, suggest no more than 4pcs in parallel. Allow to be extended up to 2 in series and 4 in parallel (Max 2S4P) to get more capacity (Max 800Ah) and higher voltage (Max 48V). Other installation methods: 2S1P, 2S2P, 2S3P, etc.
- 【Deep Cycle Battery】: CHINS LiFePO4 battery provides 4500+ cycles compared to 300~500 cycles in lead acid battery. The service life of LiFePO4 batteries is 8 to 10 times than the standard lead-acid batteries. The weight of the lithium iron phosphate battery is 30% lighter than the lead-acid battery of the same capacity. Brand: CHINS, Size: 20.47 x 10.59 x 8.66 inches, Color: Black, Orange.
- 【Built-In BMS & Convenience & Maintenance Free】: CHINS LiFePO4 battery has built-in BMS (Battery Management System) to protect it from overcharge, over-discharge, over-current, and short circuit with excellent self-discharge rate. Built-in high temp cut off prevents charging over 122 °F (50 °C). Plus, Li-Ion batteries can be safer than Lead Acid batteries, which have no protection against ground faults. This product fits for outdoor camping power and indoor easy installation.
- 【Lithium Iron Technology】: CHINS deep cycle lithium-ion battery has higher energy density, more stable performance and greater power. LiFepo4 battery will not burn when overcharged, overdischarged, overcurrent or short circuit, and can withstand high temperatures without decomposition. It can support fast charging and solar panel charging. Our LiFepo4 batteryis a green battery, it does not contain any heavy metals and rare metals and is more environmentally friendly.
- 【Widely Used】: CHINS lithium iron phosphate battery can be used in the following areas: Home energy storage system, UPS backup, lighting, digital/CCTV cameras, portable TV, e-Robot, electric vehicles, DIY loud speaker, 12V router, air pump, fish finder, golf cart, trolling motor, motorhome/RV & camper, Houseboat, Travel Trailer, Dump Trailer and more. When the batteries are used in parallel or series, the battery voltage and capacity must be the same, and purchased in near time(within 6 month).
- 【Special Note】: If the load you are using contains trolling motor, the maximum continuous output current of our battery must be twice of the motor. Otherwise, our batteries cannot run your device. You can also consult us about this issue before purchasing the product, our engineers will give you the advice. In addition, our batteries cannot be used as a car starter battery. The max parallel connections for 24V 200AH lifepo4 battery is 4 and the maximum series-parallel combination is 2S4P.
Details: CHINS Bluetooth 24V 200Ah (BMS:200A) LiFePO4 Battery Product Parameters
Rated Capacity (0.2C): 200Ah / 5120Wh
Impedance: ≤ 6mΩ
Terminal: M8
BMS Board: 200A
Rated voltage: 25.6V
Operating temperatures:
Charge temperatures: 0°C~50°C(32°F~122°F)
Discharge temperatures: -20°C~60°C(-4°F~140°F)
Storage temperatures： -10°C~35°C(14°F~95°F)
Charge voltage: 28.4V - 29.2V Depth of Discharge (DOD): 100%
Max charge current: 200A
Max continuous discharge current: 200A
Standard charge current: 50A
Charging time: Approximately 5 hours
Peak discharge current: 600A (Duration: less than 3 seconds)
Dimensions: 20.47 x 10.59 x 8.66 inches
Weight: 86.4LB
Our lifepo4 battery 24V 200AH has built-in 200A BMS (Battery Management System) to
protect it from overcharge, over-discharge, over-current, and short circuit and high temperature cut off.
Special Note: If the load you are using contains trolling motor, the maximum
continuous output current of our battery must be twice of the motor.
Otherwise, our batteries cannot run your device. You can also consult
us about this issue before purchasing the product, our engineers will give you the advice. In addition, our batteries cannot be used as a car starter battery.
If the maximum current of the motor is less than 100A, you can buy CHINS 24V 200AH LiFePO4 battery.
CHINS's factory is equipped with the most advanced R&D team and equipment,
and has passed UL, CE, RoHS, WEEE and PSE quality system certification.
With 20 years of battery expertise, CHINS has always contributed to a green life, we firmly believe that "Green Leads Life".
EAN: 0755471956317
Part Number: LAF24200
